SAAS Seats are best fitted in conjunction with either of the following components:
The process of putting a new seat in your vehicle requires a custom subframe (providing an attachment point to the vehicle floor). We recommended you consult an approved engineer to fabricate mounting brackets - accredited engineers can also supply you with a seating label which reflects the new seating arrangements.
Subframe Mounts | 345mm (W) x 275mm (D) |
Mounting Boss | 4 x M8x1.25 |
Seat Winder | SSK101 |
Seat Side Cover Plate | SSC102 |
Seat Cover Grommet Kit | SSG103 |
ADR Compliance | ADR 3/02 - Seat and Seat Anchorages 2005 |
Seat and Anchorage Longitudinal 20g Test | ADR 3/02 5.5.1.1 & 5.5.2 |
Rearward Backrest Test | ADR 3/02 5.5. 3 |
Energy Dissipation Test | ADR 3/02 6.4 |
Head Restraint Test | ADR 22/00 |
SKU | E1002 |
Barcode | 9348391005299 |
Length | 1350mm |
Width | 580mm |
Height | 320mm |
Cubic | 0.2506m³ |
Weight | 20.00kg |
