Keep an eye on your vehicle's engine oil temperature and be on the alert for possible overheating or other potential engine issues.
The sender is most commonly piggy backed off the OE oil pressure sender/switch using a brass T-Adaptor. If that's already being used for an oil pressure gauge, consider using a SAAS oil filter sandwich plate that provides up to 3 sender ports for accessories.
Should the standard sender wire not be long enough, splice in an additional length of wire with a gauge NO GREATER than supplied loom wire. SAAS recommends <= 20AWG wire. Use of a heavier gauge wire or of too greater length will impact resistance and distort temperature readings.
Series | Muscle Series I |
Body OD | 52mm / 2" |
Range | 50°-150° |
Lighting | LED Multi-select 4 Colour |
Type | Electronic |
Bracket Mounting | SG31005 |
Sender Oil Temp | SG31001 |
Sender Thread | 1/8" NPT |
Sender Adaptors | List Adaptors |
Wiring Loom | SG3121 |
Download | Fitting Instructions |
SKU | SG-OT52W |
Barcode | 9348391007286 |
Length | 150mm |
Width | 125mm |
Height | 95mm |
Cubic | 0.0018m³ |
Weight | 0.40kg |
